Sphere dedicated fiber laser marking machine
Sphere dedicated fiber laser mark↕λ↓ing machine
Specifications:

Device model: QT-GQ50

Laser power: 50W

Laser wavelength: 1064nm

Beam quality (M2): ≤1.8

Laser repetition frequency: 20 ~ 20✘‍δ÷0KHz

Marking range: 220 × 220 (mm≠↕)

Maximum linear speed: 9000mm / s®ε

Minimum line width: 0.03mm

Minimum character: 0.15

Cooling method: air c♣≤ooling

Total power consumption: 800W

Power demand: 220V / 50Hz

Appearance size: 1460 * 730 * 144ε₩​♠0 (mm)

Feature description

1. This machine is customized an↓✔d can be equipped with a variety o $f light sources (ultraviolet, green li& "£ght, optical fiber, CO2, MOPA)★ε>;

2. At present, this machine  ε₩₹is equipped with fiber laser;

3. Adopt optical fiber outδ γput, configure high-speed digital scannσφ™€ing head, marking speed is 20 times thaΩφ&↓t of traditional model$$  s;

4. The electro-optic conversi✘ ε>on rate is as high as 30%, and the po₹ ★wer consumption is about 10% of t↓​he traditional model;

5. Using the most advα±∏anced 3D laser projection technology↑→π, the sphere can be fully coverα"≈®ed in 360 degrees, and markiβφng can be completed a>π​Ωt one time

6. Marking with five-axis sim¶φ♦φultaneous motion: scanning gaδ≈lvanometer 3 axis, frame 2 axis;

7. Any content can be marked on the sp≥ ∏♥here, such as: marking on theδ$ globe, engraving the earth's lati ★♠±tude and longitude, Ch≈★inese and English chara ✘α×cters, patterns, patterns;

8. High marking accuracy: it ca πγ←n satisfy marking a large amount>‌Ω of information on extre€"mely small objects. Foδ™r example, a fine and clear world map "₽₩♥can be marked on a small → ×sphere around 10cm;

9. Cooling by air cooling, the♦✘ whole machine is small and≤♦  compact;

10. No consumables, maintenance§ "₽-free, and long service life.

Application area

It is mainly used for marking sp§∑≤"heres and round objects of varσφ÷ious metal materials¶∏. It can also be used to mark me©'tal and non-metallic materia∑δε☆ls with high ignition poin¶‍§ts, such as electronic components, har<≤∑÷dware tools, electronic produc→♠£♠ts, consumer goods, sensors, auto ≤•∑₩parts, crafts, precision i♠♥€nstruments, gift acces" £sories, sanitary ware, etc.

Sample show
